Model NO.:
LW-COB013
Quantity:
  • IP Rank:IP20,IP67
  • Color:CW,WW,
  • Type::Flexible COB Led Strip
  • Voltage:DC 12/24V
  • LED Quantity:504leds/m
  • Application:Decorative Lighting
  • Product Name:Cob led strip
  • PCB Color:white,
  • Warranty:2years
  • Lamp Luminous Efficiency(lm/w):100
  • Color Rendering Index(Ra):90
  • Support Dimmer:Yes
  • Lighting solutions service:Lighting and circuitry design
  • Lighting solutions service:Project Installation
  • Working Time (hours):50000
  • Lamp Body Material:Copper
  • Certification:ce
  • Certification:EMC
  • Certification:FCC
  • Certification:LVD
  • Certification:RoHS
  • Certification:Reach
  • Certification:Saa
  • Certification:VDE
  • Application:Hotel
  • Light Source:LED
  • Switch Mode:Remote Control
  • IP Rating:Ip20
  • Place of Origin:CN
  • Input Voltage(V):DC 24V
  • Lamp Power:12W-14W/M
  • CRI (Ra>):90
  • Working Temperature(℃):-20 - 60
  • Working Lifetime(Hour):50000
  • Brand Name:ledworker
  • Model Number:LW-COB013
  • Warranty(Year):2-Year
Product Description
Advantage:
1, 378pcs COB strip
2, High effective LM
1, 480pcs COB strip
2, Economy type
1, 480pcs COB strip
2, Three different 6/8/10mm width Choose
1, 504pcs COB strip
2, High brightiness
1, 512pcs COB strip
2, Single Red, Single Blue, Single Green
Part NO:
LW-COB003
LW-COB012
LW-COB013
LW-COB005
LW-COB014
LED Qty:
378pcs per meter
480pcs per meter
480pcs per meter
504pcs per meter
512pcs per meter
CRI (RA)
90
80
90
90
90
PCB Width IP20:
10mm width
8mm width
10mm width
10mm width
8mm width
Input Voltage:
DC24V /12
DC24V /12
DC24V /12
DC24V
DC24V
Watts:
DC24V=14W /12V=10W
9W
DC24V=14W /12V=10W
DC24V=14W
DC24V=10W
Luminous Flux:
100LM / W
90LM / W
100LM / W
100LM / W
.–
Color:
2700/3000/4000/6000K
2700/3000/4000/6000K
2700/3000/4000/6000K
2700/3000/4000/6000K
R or G or B
PCB color:
White
White
White
White
Red, Green, Blue
IP Grade:
IP20
IP20
IP20
IP20
IP20
Operating temperature:
.-25 to 45℃
.-25 to 45℃
.-25 to 45℃
.-25 to 45℃
.-25 to 45℃
Beam angle:
180 degree
180 degree
180 degree
180 degree
180 degree
Certification:
CE; RoHS
CE; RoHS
CE; RoHS
CE; RoHS
CE; RoHS
Max Run:
5M
5M
5M
5M
5M
Min Run:
24V 55.5mm
12V 23.8mm
24V 50mm
12V 25mm
24V 50mm
12V 25mm
24V 41.67mm
12V 23.8mm
24V 62.5mm

Productdetails:

1. New Technology, Chips On PCB Directly. Dot Free type.
2. High Color Efficiency, Uniform Illumination.
3. Single Color: 2700k, 3000k, 4000k, 6000k , Red, Green, Blue, Yellow. Also have RGB COB, Dual color type, 360 degree COB Led
Strip. Constant current /High Voltage Type is developing.
4. All of Materials Are Accord With Rohs / CE / REACH Standards.
5. Easy to Install and Preserve;can Be Bent Freely; With 3m Adhesive Tape On the Backside.
6. Beam Angle 180°.
7. As a manufacturer, we can customize different lengths, board width, voltage, power, color temperature and color rendering index
according to customer requirements.

12V-504leds

24V-504leds

Connect drawing:
